FUJITSU F2MCTM-16LX User Manual
Page 548
532
CHAPTER 24 512K-BIT FLASH MEMORY
Figure 24.2-2 Sector Configuration of the 512K-bit Flash Memory
MB90F362/T(S),
MB90F367/T(S)
7FFFF
H
70000
H
FFFFFF
H
FF0000
H
Programmer
address*
CPU
address
SA0 (64K bytes)
*: The programmer address is equivalent to the CPU address when data is written to the flash memory using a paral-
lel programmer. When a general programmer is used for writing/erasing, this address is used for writing/erasing.
