98
CHAPTER 5 CLOCKS
5.3 Clock Selection Register (CKSCR)
The clock selection register (CKSCR) is used to switch among the main clock, PLL
clocks and subclock, also used to select an oscillation stabilization wait interval and a
PLL clock multiplier.
■ Configuration of the Clock Selection Register (CKSCR)
Figure 5.3-1 Configuration of the Clock Selection Register (CKSCR)
bit9 bit8
CS2 CS1 CS0
Multiplication rate select bit
Parenthesized values are examples calculated at
an oscillation clock (HCLK) frequency of 4 MHz.
0 0 0 1 × HCLK (4 MHz)
0 0 1 2 × HCLK (8 MHz)
0 1 0 3 × HCLK (12 MHz)
0 1 1 4 × HCLK (16 MHz)
1 1 0 6 × HCLK (24 MHz)
1 1 1 Setting disabled
bit10
MCS PLL clock select bit
0 Select PLL clock
1 Select main clock
bit11
SCS Sub clock select bit
0 Select sub clock
1 Select main clock
bit13 bit12
WS1 WS0
Oscillation stabilization wait time select bit
Parenthesized values are examples calculated at an
oscillation clock (HCLK) frequency of 4 MHz.
0 0 2 10 /HCLK (approx. 256 µ s)
0 1 2 13 /HCLK (approx. 2.05 ms)
1 0
2
17
/HCLK (approx. 32.77 ms)
1 1
2
15
/HCLK ( approx. 8.19 ms, other than power-on reset)
2
16
/HCLK ( approx. 16.38 ms, power-on reset only)
bit14
MCM PLL clock operation bit
0 Operating in PLL clock
1 Operating in main clock or sub clock
bit15
SCM Sub clock operation bit
0 Operating in sub clock
1 Operating in main clock or PLL clock
Address 15 14 13 12 11 10 9 8 Reset value
0000A1
H
SCM MCM WS1 WS0 SCS MCS CS1 CS0 11111100
B
R R R/W R/W R/W R/W R/W R/W
CS2(PSCCR register: bit8)
HCLK : Oscillation clock
R/W : Read/Write
R : Read only
: Reset value
