CHAPTER 14 16-BIT RELOAD TIMER
14.3.2 Timer Control Status Registers (Low) (TMCSR: L)
The timer control status registers (Low) (TMCSR:L) enables or disable the timer
operation, check the generation of a software trigger or an underflow, enables or
disable an underflow interrupt, select the reload mode, and set the output of the TOT
pin.
■ Timer Control Status Registers (Low) (TMCSR: L)
Figure 14.3-4 Timer Control Status Registers (Low) (TMCSR: L)
∗
0 0 0 0 0 0 0 0 B
4 5 3 2 1 6
R/W R/W R/W R/W R/W R/W R/W
0 7
TMCSR2 : 000064 H
TMCSR3 : 000066 H
TRG CNTE UF INTE RELD OUTL OUTE
R/W : Read/Write
: Reset value
∗ : For MOD0 (bit 7), see "14.3.1 Timer Control Status Registers (High) (TMCSR:H)".
Reset value
Address:
bit0
TRG Software trigger bit
0 No effect
1 After reloading, starts counting
bit1
CNTE Timer operation enable bit
0 Timer operation disabled
1 Timer operation enabled (wait start trigger)
bit2
UF
Underflow generating flag bit
Read Write
0 No underflow Clear UF bit
1 Underflow No effect
bit3
INTE Underflow interrupt enable bit
0 Underflow interrupt disable
1 Underflow interrupt enable
bit4
RELD Reload select bit
0 One-shot mode
1 Reload mode
bit5
OUTL
TOT pin output level select bit
One-shot mode (RELD=0) Reload mode (RELD=1)
0
High rectangular wave output
during counting
Low toggle output at starting reload timer
1
Low rectangular wave output
during counting
High toggle output at starting reload timer
bit6
OUTE
TOT pin output enable bit
Pin function
0 General-purpose I/O port
1 TOT output
