380
CHAPTER 19 LOW VOLTAGE DETECTION/CPU OPERATING DETECTION RESET
19.6 Sample Program for Low Voltage/CPU Operating Detection
Reset Circuit
This section shows the sample program for low voltage/CPU operating detection reset
circuit.
■ Sample Program for Low Voltage/CPU Operating Detection Reset Circuit
●
Processing specification
The counter of CPU operating detecting function is cleared.
●
Coding example
LVRC EQU 006EH ; Address of low voltage/CPU operating detection reset control register
-------------------------------------Main program-------------------------------------
CSEG ; [CODE SEGMENT]
:
MOV LVRC,#00110101B
:
END
