APPENDIX B Instructions
Note:
m: RW0 value (counter value), n: Loop count
See Table B.5-1 and Table B.5-2 for information on (a) to (d) in the table.
Table B.8-18 10 String Instructions
Mnemonic
#
RG
B
Operation
L
H
A
H
I
S
T
N
Z
V
C
R
M
W
MOVS / MOVSI
2
*2
*5
*3
byte transfer @AH+ <-- @AL+, counter = RW0
-
-
-
-
-
-
-
-
-
-
MOVSD
2
*2
*5
*3
byte transfer @AH- <-- @AL-, counter = RW0
-
-
-
-
-
-
-
-
-
-
SCEQ / SCEQI
2
*1
*5
*4
byte search @AH+ <-- AL, counter RW0
-
-
-
-
-
*
*
*
*
-
SCEQD
2
*1
*5
*4
byte search @AH- <-- AL, counter RW0
-
-
-
-
-
*
*
*
*
-
FILS / FILSI
2
6m+6
*5
*3
byte fill @AH+ <-- AL, counter RW0
-
-
-
-
-
*
*
-
-
-
MOVSW / MOVSWI
2
*2
*5
*6
word transfer @AH+ <-- @AL+, counter = RW0
-
-
-
-
-
-
-
-
-
-
MOVSWD
2
*2
*5
*6
word transfer @AH- <-- @AL-, counter = RW0
-
-
-
-
-
-
-
-
-
-
SCWEQ / SCWEQI
2
*1
*5
*7
word search @AH+ - AL, counter = RW0
-
-
-
-
-
*
*
*
*
-
SCWEQD
2
*1
*5
*7
word search @AH- - AL, counter = RW0
-
-
-
-
-
*
*
*
*
-
FILSW / FILSWI
2
6m+6
*5
*6
word fill @AH+ <-- AL, counter = RW0
-
-
-
-
-
*
*
-
-
-
*1: 5 when RW0 is 0, 4 + 7 x (RW0) when the counter expires, or 7n + 5 when a match occurs
*2: 5 when RW0 is 0; otherwise, 4 + 8 x (RW0)
*3: (b) x (RW0) + (b) x (RW0) When the source and destination access different areas, calculate the (b) item individually.
*4: (b) x n
*5: 2 x (RW0)
*6: (c) x (RW0) + (c) x (RW0) When the source and destination access different areas, calculate the (c) item individually.
*7: (c) x n
