CHAPTER 15 WATCH TIMER
15.3 Configuration of Watch Timer
This section explains the registers and interrupt factors of the watch timer.
■ List of Registers and Reset Values of Watch Timer
Figure 15.3-1 List of Registers and Reset Values of Watch Timer
■ Generation of Interrupt Request from Watch Timer
• When the interval time set by the interval time select bits (WTC:WTC2 to WTC0) is reached, the
overflow flag bit (WTC:WTOF) is set to "1".
• When the overflow flag bit is set (WTC:WTOF = 1) with interrupt enabled when the watch timer
counter overflows (carries) (WTC:WTIE = 1), an interrupt request is generated.
1 0 0 0 0
×
6 5 4 3 2 1
0 1
7 0 bit
Address: 0000AA
H
✕ : Undefined
Watch timer control register (WTC)
