CHAPTER 18 8-/10-BIT A/D CONVERTER

18.1

Overview of 8-/10-bit A/D Converter

The 8-/10-bit A/D converter converts the analog input voltage to a 8- or 10-bit digital
value by using the RC sequential-comparison converter system.
• An input signal can be selected from the input signals of the analog input pins for 16

channels.

• The start trigger can be selected from a software trigger and an external trigger.

Function of 8-/10-bit A/D Converter

The 8-/10-bit A/D converter converts the analog voltage (input voltage) input to the analog input pin into

an 8- or 10-bit digital value (A/D conversion).

The 8-/10-bit A/D converter has the following functions:

A/D conversion time is a minimum of 1.9

µs

*

per channel including sampling time.

Sampling time is a minimum of 0.5

µs

*

per channel.

RC sequential-comparison converter system with sample & hold circuit

Setting of 8-bit or 10-bit resolution enabled

Analog input pin can be used up to 16 channels.

Generates interrupt request by storing A/D conversion results in A/D data register

Starts EI

2

OS if interrupt request generated. Use of the EI

2

OS prevents data loss even at continuous A/D

conversion.

Selects start trigger from software trigger and external trigger (falling edge)

*: When the machine clock frequency operates at 24 MHz and AV

CC

≥ 4.5 V.

Conversion Modes of 8-/10-bit A/D Converter

There are 3 conversion modes of 8-/10-bit A/D converter as shown below:

Table 18.1-1 Conversion Modes of 8-/10-bit A/D Converter

Conversion

Mode

Description

Single-shot
conversion mode

A/D conversion is performed sequentially from the start channel to the end channel.
When A/D conversion for the end channel is terminated, it stops.

Continuous
conversion mode

A/D conversion is performed sequentially from the start channel to the end channel.
When A/D conversion for the end channel is terminated, it is continued after
returning to the start channel.

Pause-conversion
mode

A/D conversion is performed pausing per channel. When A/D conversion for the
end channel is terminated, A/D conversion and pause are repeated after returning to
the start channel.
