364
CHAPTER 18 8-/10-BIT A/D CONVERTER
18.5.3 Pause-conversion Mode
In the pause-conversion mode, A/D conversion starts and pauses repeatedly for each
channel. When the start trigger is inputted after the A/D conversion pauses at the
termination of the A/D conversion for the end channel, A/D conversion is continued after
returning to the start channel.
■ Setting of Pause-conversion Mode
Operating the 8-/10-bit A/D converter in the pause-conversion mode requires the setting shown in Figure
18.5-3 .
Figure 18.5-3 Setting of Pause-conversion Mode
PAUS STS1 STRT STS0 BUSY INT INTE ADCS
1 1 0
MD1 S10 MD0
− − − − −
− − − − −
−
CT1 CT2 CT0 ST1 ST2 ST0
ADCR
ADER5
bit15 14 13 12 11 10 9 bit8 bit7 6 5 4 3 2 1 bit0
ADSR ANS1 ANS0 ANE1 ANE0 ANE2 ANE3 ANS2 ANS3
ADER6
ADE15ADE14ADE13ADE12ADE11ADE10 ADE9 ADE8
ADE7 ADE6 ADE5 ADE4 ADE3 ADE2 ADE1 ADE0
1
0
−
0 0
Re-
served
D9 to D0 (Converted data stored)
: Setting 1
: Set the bit corresponding to pin to be used as analog input pin to 1.
: Used bit
: Undefined
Re-
served
Re-
served
: Setting 0
