FUJITSU F2MCTM-16LX User Manual
Page 317
301
CHAPTER 16 8-/16-BIT PPG TIMER
16.5.1
8-bit PPG Output 2-channel Independent Operation Mode
In the 8-bit PPG output 2-channel independent operation mode, the 8-/16-bit PPG timer
is set as an 8-bit PPG timer with two independent channels. PPG output operation and
interrupt request generation can be performed independently for each channel.
■
Setting for 8-bit PPG Output 2-channel Independent Operation Mode
Operating the 8-/16-bit PPG timer in the 8-bit PPG output 2-channel independent operation mode requires
the setting shown in Figure 16.5-2 .
Figure 16.5-2 Setting for 8-bit PPG Output 2-channel Independent Operation Mode
Note:
Use the word instruction to set both High-level and Low-level PPG reload registers (PRLLn/PRLHn and
PRLLm/PRLHm) at the same time.
PIE1 PUF1
MD0
MD1
PEN1
−
PE1
PPGCm/PPGCn
1
0
0
1
1
1
PIE0 PUF0
−
−
PEN0
−
PE0
PPGnm
PCM2 PCM1
−
REV
PCM0
PCS2 PCS1 PCS0
bit15 14
13
12
11
10
9
bit8 bit7
6
5
4
3
2
1
bit0
PRLHn/PRLLn
PRLHm/PRLLm
Re-
served
Re-
served
(Reserved area)
PPGn set High level side reload values.
PPGm set High level side reload values.
PPGn set Low level side reload values.
PPGm set Low level side reload values.
: Used bit
-
: Undefined bit
1
: Set 1
0
: Set 0
Note: n = C, E
m = n + 1
