CHAPTER 20 LIN-UART
20.4 LIN-UART Registers
The following figure shows the LIN-UART registers.
■ LIN-UART Registers
Figure 20.4-1 LIN-UART Registers
• LIN-UART0
Address: bit 15 bit 8 bit 7 bit 0
000021
H
000020
H
SCR0 (serial control register) SMR0 (serial mode register)
000023
H
000022
H
SSR0 (serial status register) RDR0/TDR0 (reception data register/transmission data register)
000025
H
000024
H
ESCR0 (Extended status control register) ECCR0 (Extended communication control register)
000027
H
000026
H
BGR01 (Baud rate generator register) BGR00 (Baud rate generator register)
• LIN-UART1
Address: bit 15 bit 8 bit 7 bit 0
000029
H
000028
H
SCR1 (serial control register) SMR1 (serial mode register)
00002B
H
00002A
H
SSR1 (serial status register) RDR1/TDR1 (reception data register/transmission data register)
00002D
H
00002C
H
ESCR1 (Extended status control register) ECCR1 (Extended communication control register)
00002F
H
00002E
H
BGR11(Baud rate generator register) BGR10(Baud rate generator register)
