599
APPENDIX B Instructions
#imm4 4-bit immediate data
#imm8 8-bit immediate data
#imm16 16-bit immediate data
#imm32 32-bit immediate data
ext (imm8) 16-bit data obtained by sign extension of 8-bit immediate data
disp8 8-bit displacement
disp16 16-bit displacement
bp Bit offset
vct4 Vector number (0 to 15)
vct8 Vector number (0 to 255)
( ) b Bit address
rel PC relative branch
ear Effective addressing (code 00 to 07)
eam Effective addressing (code 08 to 1F)
rlst Register list
Table B.7-2 Explanation on Symbols in the Instruction List (2/2)
Symbol Explanation
