AT-S62 Management Software Menus Interface User’s Guide
Section VII: Management Security 771
Displaying the ACEs
To display the ACEs in the management ACL, perform the following
procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 52.
2. From the System Administration menu, type 7 to select Management
ACL.
The Management ACL Configuration menu is shown in Figure 260 on
page 764.
3. From the Management ACL Configuration menu, type 5 to select
Display All Management ACL Entries.
The Display All Management ACL Entries menu is shown in
Figure 262.
Figure 262. Display All Management ACL Entries Menu
The menu provides the following information about the ACEs:
ID
The entry’s identification number.
IP Address
The IP address of a management station or a subnet.
Mask
The parts of the IP address the switch is filtering on.
Application
The application that the management station is permitted to use to
manage the switch. The options are Telnet, Web, Ping and All.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Marketing
User: Manager 11:20:02 02-Mar-2006
Display All Management ACL Entries
ID IP Address Mask Application
------------------------------------------------------
1
133.22.145.18 255.255.255.255 All
2 133.22.146.0 255.255.255.0 Web
U - Update display
R - Return to Previous Menu
Enter your selection?
