Chapter 16: Class of Service
320 Section II: Advanced Operations
Displaying Port CoS Priorities
The following procedure displays a menu that lists the current CoS priority
level settings for each port.
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 103 on page 313.
2. From the Security and Services menu, type 5 to select Class of
Service (CoS).
The Class of Service (CoS) menu is shown in Figure 104 on page 314.
3. From the Class of Service (CoS) menu, type 4 to select Show Port
CoS Priorities.
The Show Port CoS Priorities menu is shown in Figure 108.
Figure 108. Show Port CoS Priorities Menu
The PVID column displays the identifier of the VLAN where the port is
an untagged member.
The Priority column displays the temporary priority level assigned to
ingress untagged packets on the port.
The Override Priority column indicates whether the priority level in
ingress tagged frames is being used or not. If No, the override is
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Show Port CoS Priorities
Port PVID Priority Override Priority
---------------------------------------------
01 1 0 No
02 1 0 No
03 1 0 No
04 1 0 No
05 1 0 No
06 1 0 No
07 1 0 No
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
