AT-S62 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 283
Managing Flow Groups
This section contains the following procedures:
ˆ “Creating a Flow Group” on page 283
ˆ “Modifying a Flow Group” on page 285
ˆ “Deleting a Flow Group” on page 287
ˆ “Displaying Flow Groups” on page 288
Creating a Flow
Group
To create a flow group, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 87.
Figure 87. Quality of Service (QoS) menu
3. From the Quality of Service (QoS) menu, type 1 to select Flow Group
Configuration.
The Flow Group Configuration menu is shown in Figure 88.
Figure 88. Flow Group Configuration Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Quality of Service (QoS)
1 - Flow Group Configuration
2 - Traffic Class Configuration
3 - Policy Configuration
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Flow Group Configuration
1 - Create Flow Group
2 - Modify Flow Group
3 - Destroy Flow Group
4 - Show Flow Groups
R - Return to Previous Menu
Enter your selection?
