Chapter 8: Static and LACP Port Trunks
162 Section I: Basic Operations
Figure 44 is an example of the LACP (IEEE 802.3ad Port Status menu.
The information in this window is for viewing purposes only. For
definitions, refer to the IEEE 802.3ad standard.
Figure 44. LACP (IEEE 802.3ad Port Status Menu
Figure 45 is an example of the LACP (IEEE 802.3ad) Aggregator
Status menu. The information is for viewing purposes only. An
aggregator appears in the menu only if there is at least one active
aggregate trunk between the switch and another network device.
Figure 45. LACP (IEEE 802.3ad) Aggregator Status Menu
LACP (IEEE 802.3ad) Port Status
Port ............. 01
Aggregator ....... Sales server
ACTOR PARTNER
====================================++++++++===========================
Actor Port ............. 06
Partner Port ......... 00
Selected ............... SELECTED Partner System ....... 00-30-84-00-00-02
Oper Key ............... 0x0050 Oper Key ............ 0x0004
Oper Port Priority .... 0x0006 Oper Port Priority ... 0x0007
Individual ............. NO Individual ........... NO
Synchronized............ YES Synchronized.......... YES
Collecting ............ YES Collecting ........... YES
Distributing ........... YES Distributing ......... NO
Defaulted .............. NO Defaulted ............ NO
Expired ................ NO Expired .............. NO
Actor Churn .......... YES Partner Churn ........ YES
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
LACP (IEEE 802.3ad) Aggregator Status
Aggregator #1 ................. Sales server
Adminkey ...................... 0x0050
Oper Key....................... 0x1405
Speed ......................... 100 Mbps
Ports in LAGID ................ 1-4
Aggregated Port ............... 1-4
Mode .......................... SRC/DST MAC
LAG ID:
[(0080,00-30-84-00-00-00,0041,00,0000),(0080,00-30-84-00-00-
02,0004,00,0000)]
R - Return to Previous Menu
Enter your selection?
