Chapter 11: File Downloads and Uploads
190 Section II: Advanced Operations
Downloading an
AT-S62 Image
from a Local
Management
Session
Review the “Guidelines” on page 188 before performing the following
download procedure.
To download a new software image onto a switch from a local
management session using Xmodem or TFTP, perform the following
procedure:
1. Establish a local management session on the switch where you want
to download the new management software.
2. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 52.
3. From the System Administration menu, type 9 to select System
Utilities.
The System Utilities menu is shown in Figure 6 on page 57.
4. From the System Utilities menu, type 2 to select Downloads and
Uploads.
The Downloads and Uploads menu is shown in Figure 51.
Figure 51. Downloads and Uploads Menu
Note
The Downloads and Uploads menu for an AT-8524POE switch
includes the selection 5 - Download PoE Firmware. This selection is
intended for Allied Telesyn Technical Support only.
5. From the Downloads and Uploads menu, type 1 to select Download
Application Image/Bootloader.
The following prompt is displayed:
Download Method/Protocol [X-Xmodem, T-TFTP]:
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Downloads and Uploads
1 - Download Application Image/BootLoader
2 - Upload Application Image/BootLoader
3 - Download a file
4 - Upload a file
R - Return to Previous Menu
Enter your selection?
