Allied Telesis AT-S62 - Manual (Page 757)

AT-S62 Management Software Menus Interface User’s Guide
Section VII: Management Security 757
Figure 258. RADIUS Server Configuration
The parameters are described below:
1 - Server IP Address
Use this option to specify the IP address of the RADIUS server.
2 - Server Authentication UDP Port
Use this option to specify the UDP port of the RADIUS protocol.
3 - Server Encryption Key
Use this option to specify the encryption key for the RADIUS server.
7. After you finish configuring the parameters in the RADIUS Client
Configuration menu, type R to return to the Authentication Menu,
shown in Figure 255 on page 752.
Note
Steps 8 and 9 activate the feature. Do not enable the feature if you
have not defined the new manager username and password
accounts on the RADIUS authentication server. Otherwise, you will
not be able to initiate future management sessions with the switch.
8. From the Authentication Menu, type 1 to select Server-based
Authentication. The following prompt is displayed:
Server Based User Authentication (E-Enabled, D-Disabled) ->
9. Type E to enable server-based authentication on the switch.
After enabling the feature, you must use the new manager username
and password combinations that you defined on the RADIUS
authentication server when you start future management sessions on
the switch.
10. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
RADIUS Server 1 Configuration
1 - Server IP Address ................. 0.0.0.0
2 - Server Authentication UDP Port .... 1812
3 - Server Encryption Key .............
R - Return to Previous Menu
Enter your selection?
