AT-S62 Management Software Menus Interface User’s Guide
Section I: Basic Operations 159
The Port Trunking and LACP menu is shown in Figure 38 on page 148.
3. Type 2 to select LACP Configuration.
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 41
on page 155.
4. Type 4 to select Modify Aggregator.
The Modify LACP (IEEE 8023ad) Aggregator menu is shown in Figure
43.
Figure 43. Modify LACP (IEEE 8023ad) Aggregator Menu
5. Type 1 to select Aggregator or 2 for Adminkey and, when prompted,
enter the name or adminkey of the aggregator you want to modify. You
can specify the aggregator by its name or adminkey number. The
name is case-sensitive.
After you enter the aggregator’s name or adminkey, the specifications
of the aggregator are displayed in the menu.
6. Adjust the settings as necessary. The parameters are defined here:
1 - Aggregator
Specifies a name for the aggregator. The name can be up to twenty
alphanumeric characters. Spaces are allowed, but special characters,
such as asterisks and exclamation points, are not. Each aggregator
must have a unique name.
2 - Adminkey
Specifies a unique adminkey value for the aggregator. The value is
entered in hexadecimal. The range is 1 to FFFF. For background
information, refer to “Adminkey Parameter” on page 142.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Modify LACP (IEEE 802.3ad) Aggregator
1 - Aggregator ..................
2 - Adminkey .................... 0x0000
3 - Distribution Mode ........... SRC/DST MAC
4 - Port Range ..................
M - Modify Aggregator
R - Return to Previous Menu
Enter your selection?
