AT-S62 Management Software Menus Interface User’s Guide
Section I: Basic Operations 149
DST IP Destination IP address.
SRC/DST IP Source address/destination IP address.
ˆ Status - The operational status of the trunk. Up means at least one
port in the trunk has established a link with a port on the other
device. Down means no ports in the trunk have established a link
with the other device.
4. Type C to select Create Trunk.
The Create Trunk menu is shown in Figure 39.
Figure 39. Create Trunk Menu
5. Type 1 to select Trunk ID and, when prompted, enter an ID number for
the trunk of from 1 to 6. A trunk must be assigned a unique ID number.
The default value is the next unused ID number.
6. Type 2 to select Trunk Name and, when prompted, enter a name for
the trunk. The name can be up to sixteen alphanumeric characters. No
spaces or special characters, such as asterisks and exclamation
points, are allowed. Each trunk must have a unique name.
7. To set the load distribution method, type 3 to toggle the selection
through the following possible settings:
ˆ SRC MAC - Source MAC address
ˆ DST MAC - Destination MAC address
ˆ SRC/DST MAC - Source address /destination MAC address
ˆ SRC IP - Source IP address trunking
ˆ DST IP - Destination IP address trunking
ˆ SRC/DST IP - Source address /destination IP address
The default is SRC/DST MAC. For background information, refer to
“Load Distribution Methods” on page 144.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Create Trunk
1 - Trunk ID ......... 1
2 - Trunk Name .......
3 - Trunk Method ..... SRC/DST MAC
4 - Trunk Ports ......
C - Create Trunk
R - Return to Previous Menu
Enter your selection?
