Chapter 15: Quality of Service
284 Section II: Advanced Operations
4. Type 1 to select Create Flow Group.
The Create Flow Group menu is shown in Figure 89.
Figure 89. Create Flow Group Menu
5. Configure the parameters as needed. The parameters are described
below:
1 - Flow Group ID
Specifies an ID number for the flow group. Each flow group on the
switch must have a unique number. The range is 0 to 1023. The
default is 0. This parameter is required.
2 - Description
Specifies a description for the flow group. The description can be from
1 to 15 alphanumeric characters including spaces. This parameter is
optional, but recommended. Names can help you identify the groups
on the switch.
3 - DSCP value
Specifies a replacement value to write into the DSCP (TOS) field of the
packets. The range is 0 to 63.
A new DSCP value can be set at all three levels: flow group, traffic
class, and policy. A DSCP value specified in a flow group overrides a
DSCP value specified at the traffic class or policy level.
4 - Priority
Specifies a new user priority value for the packets. The range is 0 to 7.
If you specify a new user priority value here and in Traffic Class, the
value here overrides the value in Traffic Class. If you want the packets
to retain the new value when they exit the switch, change option 5,
Remark Priority, to Yes.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Mar-2006
Create Flow Group
1 - FlowGroup ID .............. 0
2 - Description ...............
3 - DSCP value ................
4 - Priority ..................
5 - Remark Priority ........... No
6 - ToS .......................
7 - Move ToS to Priority ...... No
8 - Move Priority to ToS ...... No
9 - Classifier List ...........
C - Create Flow Group
R - Return to Previous Menu
Enter your selection?
