AT-S62 Management Software Menus Interface User’s Guide
Section VI: Port Security 641
Displaying Port Security Levels
To view the current security levels for the ports on the switch, do the
following:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 5 to select Port Security.
The Port Security menu is shown in Figure 218 on page 637.
3. From the Port Security menu, type 2 to select Display Port Security.
The Display Port Security menu is shown in Figure 221.
Figure 221. Display Port Security Menu
This menu is for viewing purposes only. The columns in the menu are
defined below:
Port
The number of the port.
Security Mode
The active security mode on the port.
Threshold
This column specifies the maximum number of dynamic MAC
addresses the port will learn. This applies when a port is operating in
the Limited security mode.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Display Port Security
Port Security Mode Threshold Intruder Action Participating
----------------------------------------------------------------
1
Limited 6 Trap Yes
2 Limited 10 Trap Yes
3 Automatic --- ------ ---
4 Locked --- ------ ---
5 Automatic --- ------ ---
6 Automatic --- ------ ---
7 Automatic --- ------ ---
8 Secured --- ------ ---
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
