Chapter 25: GARP VLAN Registration Protocol
602 Section V: VLANs
GVRP Database Option 2 - Display GVRP Database in the Other GARP Port Parameters
displays the GVRP Database Menu as shown in Figure 207.
Figure 207. GVRP Database Menu
The columns in the menu are defined in Table 22. The information is for
viewing purposes only.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
GVRP Database
GARP Application: GVRP
GID index
VLAN ID Used GID index VLAN ID Used
-------------------------------------------------------------------
0 1 Yes 1 3 Yes
2 2 Yes
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 22. GARP Database Parameters
Parameter Meaning
GARP Application Identifies the GARP application, that is,
“GVRP”.
GID index Value of the GID index corresponding to the
attribute. GID indexes begin at 0. If the GARP
application has no attributes presently
registered, “No attributes have been
registered” is displayed.
VLAN ID Value of the attribute.
Used Indicates whether the GID index is currently
being used by any port in the GARP
application. The definition of “used” is
whether the Applicant and Registrar state
machine for the GID index are in a non-
initialized state, that is, not in {Vo, Mt} state.
The value of this parameter is either “Yes” or
“No”.
