Chapter 24: Port-based and Tagged Virtual LANs
566 Section V: VLANs
The following prompt is displayed:
Enter new value -> [1 to 4096] ->
5. Enter the VID of the VLAN you want to modify.
The Modify VLAN menu expands to contain all relevant information
about the VLAN, as shown in Figure 192.
Figure 192. Expanded Modify VLAN Menu
6. Change the VLAN’s information as desired.
The selections in the menu are described below:
1 - VLAN Name
Use this selection to change the name of a VLAN. The name can be
from one to twenty characters in length. The name should reflect the
function of the nodes that will be a part of the VLAN (for example,
Sales or Accounting). The name cannot contain spaces or special
characters, such as asterisks (*) or exclamation points (!).
When changing a VLAN’s name, observe the following guidelines:
ˆ A VLAN’s new name cannot be the same as the name of another
VLAN on the same switch. For example, if the switch already
contains a VLAN called Sales, you cannot change an existing
VLAN’s name to Sales.
ˆ You cannot change the name of the Default_VLAN.
Note
A VLAN must have a name.
2 - VLAN ID (VID)
This is the VLAN’s VID value. You cannot change this value.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Modify VLAN
1 - VLAN Name .............. Sales
2 - VLAN ID (VID) .......... 3
3 - Tagged Ports ........... 7,9
4 - Untagged Ports ......... 20-24
5 - Protected Ports ........ No
M - Modify VLAN
R - Return to Previous Menu
Enter your selection?
