AT-S62 Management Software Menus Interface User’s Guide
Section I: Basic Operations 109
Configuring Port Parameters
To configure the parameter settings of a port, perform the following
procedure:
1. From the Main Menu, type 1 to select Port Configuration.
The Port Configuration menu is shown in Figure 21 on page 106.
2. From the Port Configuration menu, type 1 to select Port Configuration.
The following prompt is displayed:
Enter port-list ->
3. Enter the number of the port you want to configure. You can specify
more than one port at a time. You can specify the ports individually (for
example, 5,7,22), as a range (for example, 18-23), or both (for
example, 1,5,14-22).
To configure a GBIC or SFP module in Port 49 or 50 of an AT-8550GB
or AT-8550SP switch, there must be a valid connection between the
port and the end node. Otherwise, specifying Port 49 or 50 configures
the twisted pair port 49R or 50R, respectively.
The Port Configuration menu is shown in Figure 23.
Figure 23. Port Configuration (Port) Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Port Configuration
Configuring Port 11
0 - Port Description ..................... Port-1
1 - Status ............................... Enabled
2 - Broadcast Filter ..................... Disabled
3 - MDI/MDIX Crossover ................... Auto
4 - Negotiation .......................... Manual
5 - Speed ................................ 0100
6 - Duplex ............................... Full
7 - HOL Blocking Prevention Threshold .... 61440 cells
8 - Flow Control
9 - Back Pressure
L - Rate Limiting
U - Unknown Multicast Filtering .......... Disabled
D - Set Default Port Configuration
F - Force Renegotiation
X - Reset Port
R - Return to Previous Menu
Enter your selection?
