AT-S62 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 263
Deleting an ACL
This procedure deletes an ACL from the switch. In order to perform this
procedure, you need to know the ID number of the ACL you want to
delete. To display ACL ID numbers, refer to “Displaying ACLs” on
page 266.
To delete an ACL, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 4 to select Access Control
Lists.
The Access Control Lists (ACL) menu is shown in Figure 77 on page
259.
3. From the Access Control Lists (ACL) menu, type 3 to selection Destroy
ACL.
The following prompt is displayed:
Available ACL(s): 0-15
Enter ACL ID : [0 to 255] -> 0
4. Enter the ID number of the ACL you want to modify. You can modify
only one ACL at a time.
The Destroy ACL window is displayed with the specifications of the
selected ACL. You can use this window to confirm that you are deleting
the correct ACL. An example of the window is shown in Figure 80.
Figure 80. Destroy ACL Menu
Allied Telesyn Ethernet Switch AT-8524M - ATS62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Destroy ACL
1 - ACL ID ............ 25
2 - Description ....... UDP-deny
3 - Action ............ Deny
4 - Classifier List ... 32
5 - Port List ......... 15,22
D - Destroy ACL
R - Return to Previous Menu
Enter your selection?
