Chapter 8: Static and LACP Port Trunks
152 Section I: Basic Operations
ˆ SRC/DST MAC - Source address /destination MAC address
ˆ SRC IP - Source IP address trunking
ˆ DST IP - Destination IP address trunking
ˆ SRC/DST IP - Source address /destination IP address
For background information on these selections, refer to “Load
Distribution Methods” on page 144.
8. To change the ports of a trunk, type 4 to select Trunk Ports and, when
prompted, enter the new ports of the trunk. A trunk can contain up to
eight ports. You can identify the ports individually (for example,
3,7,10), as a range (for example, 5-11), or both (for example, 2,4,11-
14). The new list of ports replaces the existing ports of the trunk.
9. Type M to select Modify Trunk.
The modifications to the port trunk are activated on the switch.
10. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
11. Reconnect the cables to the ports of the trunk on the switch.
The modified port trunk is ready for network operations.
Deleting a Static
Port Trunk
To delete a static port trunk from the switch, perform the following
procedure:
Caution
Disconnect the cables from the port trunk on the switch before
performing the following procedure. Deleting a port trunk without first
disconnecting the cables can create loops in your network topology.
Data loops can result in broadcast storms and poor network
performance.
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Menu, type 4 to select Port Trunking and LACP.
The Port Trunking and LACP menu is shown in Figure 38 on page 148.
3. From the Port Trunking and LACP menu, type 1 to select Static Port
Trunking.
The Static Port Trunking menu is shown in Figure 38 on page 148.
4. Type D to select Delete Trunk.
