Chapter 15: Quality of Service
286 Section II: Advanced Operations
4. Type 2 to select Modify Flow Group.
The following prompt is displayed:
Available Flow Group(s): 0-10
Enter Flow Group ID : [0 to 1023] -> 0
5. Enter the ID number of the flow group you want to modify. You can
modify only one flow group at a time.
The selected flow group is displayed in the Modify Flow Group menu.
An example is shown in Figure 90.
Figure 90. Modify Flow Group Menu
6. Modify the settings as needed. For parameter definitions, refer to
“Creating a Flow Group” on page 283.
When modifying a flow group, note the following:
ˆ You cannot change a flow group’s ID number.
ˆ To delete a value from a variable so as to leave it blank, select the
variable and then use the backspace key to delete its default value.
ˆ Specifying an invalid value for a parameter that already has a value
causes the parameter to revert to its default value.
7. After you have finished modifying the parameter settings, type M to
select Modify Flow Group.
8. To modify another flow group, repeat this procedure starting with step
4. To assign the flow group to a traffic class, go to “Managing Traffic
Classes” on page 290.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Mar-2006
Modify Flow Group
1 - Flow Group ID .............. 2
2 - Description ................ Video1
3 - DSCP value ................. 0
4 - Priority ................... 6
5 - Remark Priority ............ No
6 - ToS ........................
7 - Move ToS to Priority ....... No
8 - Move Priority to ToS ....... No
9 - Classifier List ............ 11
M - Modify Flow Group
R - Return to Previous Menu
Enter your selection?
