Chapter 21: SNMPv3
380 Section III: SNMPv3
ˆ Security Model
ˆ Authentication Level
ˆ Privacy Protocol
ˆ Group
To configure the SNMP security information, you associate a user and its
related information—View, Security Level, Security Model, Authentication
Level, Privacy Protocol and Group—with the type of message and the
host IP address.
SNMPv3 Tables
The SNMPv3 configuration is neatly divided into configuring SNMPv3 user
information and configuring the message notification. You must configure
all seven tables to successfully configure the SNMPv3 protocol. You use
the following tables for user configuration:
ˆ Configure SNMPv3 User Table
ˆ Configure SNMPv3 View Table
ˆ Configure SNMPv3 Access Table
ˆ Configure SNMPv3 SecurityToGroup Table
First, you create a user in the Configure SNMPv3 User Table. Then you
define the MIB view this user has access to in the Configure SNMPv3
View Table. To configure a security group and associate a MIB view to a
security group, you configure the Configure SNMPv3 Access Table.
Finally, configure the Configure SNMPv3 SecurityToGroup Menu to
associate a user to a security group. See Figure 131 for an illustration of
how the user configuration tables are linked.
Figure 131. SNMPv3 User Configuration Process
SNMPv3 User Table
SNMPv3 View Table
SNMPv3 Access Table
SNMPv3 Security To Group Table
Linked by User
Name/Security
Name
Linked by View Name
Linked by Group Name
