AT-S62 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 287
9. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Deleting a Flow
Group
To delete a flow group, do the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 87 on page 283.
3. From the Quality of Service (QoS) menu, type 1 to select Flow Group
Configuration.
The Flow Group Configuration menu is shown in Figure 88 on page
283.
4. Type 3 to select Destroy Flow Group.
The following prompt is displayed:
Available Flow Group(s): 0-10
Enter Flow Group ID : [0 to 1023] -> 0
5. Enter the ID number of the flow group you want to delete. You can
delete only one flow group at a time.
The selected flow group is displayed in the Destroy Flow Group menu.
You can use the menu to verify that you are deleting the correct group.
An example is shown in Figure 91.
Figure 91. Destroy Flow Group Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Mar-2006
Destroy Flow Group
1 - Flow Group ID .............. 2
2 - Description ................ Video1
3 - DSCP value ................. 0
4 - Priority ................... 6
5 - Remark Priority ............ No
6 - ToS ........................
7 - Move ToS to Priority ....... No
8 - Move Priority to ToS ....... No
9 - Classifier List ............ 11
D - Destroy Flow Group
R - Return to Previous Menu
Enter your selection?
