Chapter 22: Spanning Tree and Rapid Spanning Tree Protocols
504 Section IV: Spanning Tree Protocols
The RSTP Port Parameters menu is shown in Figure 169.
Figure 169. RSTP Port Parameters Menu
3. Type 1 to select Configure RSTP Port Settings.
The following prompt is displayed:
Starting Port to Configure [1 to 24] ->
4. Enter the number of the port you want to configure. To configure a
range of ports, enter the first port of the range.
The following prompt is displayed:
Ending Port to Configure [1 to 24] ->
5. To configure just one port, enter the same port number here as you
entered in the previous step. To configure a range of ports, enter the
last port of the range.
The Configure RSTP Port Settings menu is shown in Figure 170.
Figure 170. Configure RSTP Port Settings Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
RSTP Port Parameters
1 - Configure RSTP Port Settings
2 - Display RSTP Port Configuration
3 - Display RSTP Port State
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Configure RSTP Port Settings
Configuring Ports 4-4
1 - Port Priority ...... 128
2 - Port Cost .......... Automatic Update
3 - Point-to-Point ..... Auto Detect
4 - Edge Port .......... Yes
R - Return to Previous Menu
Enter your selection?
