Chapter 22: Spanning Tree and Rapid Spanning Tree Protocols
486 Section IV: Spanning Tree Protocols
the bridge is communicating with the root bridge is referred to as the root
port.
If redundant paths exist, the bridges that are a part of the paths must
determine which path will be the primary, active path, and which path(s)
will be placed in the standby, blocking mode. This is accomplished by an
determination of path costs. The path offering the lowest cost to the root
bridge becomes the primary path and all redundant paths are placed into
blocking state.
Path cost is determined through an evaluation of port costs. Every port on
a bridge participating in STP has a cost associated with it. The cost of a
port on a bridge is typically based on port speed. The faster the port, the
lower the port cost. The exception to this is the ports on the root bridge,
where all ports have a port cost of 0.
Path cost is simply the sum of the port costs between a bridge and the root
bridge.
The port cost of a port on an AT-8500 Series switch is adjustable through
the management software. For STP, the range is 0 to 65,535. For RSTP,
the range is 0 to 20,000,000.
Port cost also has an Auto-Detect feature. This feature allows spanning
tree to automatically set the port cost according to the speed of the port,
assigning a lower value for higher speeds. Auto-Detect is the default
setting. Table 12 lists the STP port costs with Auto-Detect.
Table 13 lists the STP port costs with Auto-Detect when a port is part of a
port trunk.
Table 12. STP Auto-Detect Port Costs
Port Speed Port Cost
10 Mbps 100
100 Mbps 10
1000 Mbps 4
Table 13. STP Auto-Detect Port Trunk Costs
Port Speed Port Cost
10 Mbps 4
100 Mbps 4
1000 Mbps 2
