AT-S62 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 297
6. Type D to delete the traffic class.
The traffic class is deleted from the switch. The class is removed from
any policies to which it is assigned.
7. To delete another traffic class, repeat this procedure starting with step
4.
8. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
Displaying
Traffic Classes
To display the traffic classes, do the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 87 on page 283.
3. From the Quality of Service (QoS) menu, type 2 to select Traffic Class
Configuration.
The Traffic Class Configuration menu is shown in Figure 94 on page
290.
4. Type 4 to select Show Traffic Classes.
The Show Traffic Classes menu is shown in Figure 98.
Figure 98. Show Traffic Classes Menu
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Mar-2006
Show Traffic Classes
Number of Traffic Classes: 5
Parent
ID Description Policy ID Active
-------------------------------------------------------------
0
Dev database 6 Yes
1 Inv database 12 No
2 Video1 4 Yes
3 Video2 5 Yes
4 Demo dev 2 Yes
D - Display Traffic Class Details
U - Update Display
R - Return to Previous Menu
Enter your selection?
