AT-S62 Management Software Menus Interface User’s Guide
Section I: Basic Operations 151
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 37 on page 148.
3. From the Port Trunking and LACP menu, type 1 to select Static Port
Trunking.
The Static Port Trunking menu is shown in Figure 38 on page 148.
4. Type M to select Modify Trunk.
The following prompt is displayed:
Enter Trunk ID: [1 to 6] ->
5. Enter the ID number of the trunk you want to modify.
The Modify Trunk menu is displayed. The menu displays the operating
specifications of the selected trunk. An example is shown in Figure 40.
Figure 40. Modify Trunk Menu
Note
You cannot change a trunk’s ID number.
6. To modify a port trunk’s name, type 2 to select Trunk Name and, when
prompted, enter the new name for the trunk. The name can be up to
sixteen alphanumeric characters. No spaces or special characters,
such as asterisks and exclamation points, are allowed. Each trunk
must have a unique name.
7. To change the trunk’s load distribution method, type 3 to toggle the
selection through the following possible settings.
ˆ SRC MAC - Source MAC address
ˆ DST MAC - Destination MAC address
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Modify Trunk
1 - Trunk ID ......... 2
2 - Trunk Name ....... Server11
3 - Trunk Method ..... SRC/DST MAC
4 - Trunk Ports ...... 12-16
M - Modify Trunk
R - Return to Previous Menu
Enter your selection?
