Chapter 19: Power Over Ethernet
352 Section II: Advanced Operations
Displaying PoE Status and Settings
Use this procedure to display PoE status and settings at the switch or port
level.
To display PoE information, do the following:
1. From the Main Menu, type 6 to select Advanced Configuration.
2. From the Advanced Configuration menu, type 2 to select Power Over
Ethernet Configuration.
The Power Over Ethernet Configuration menu is shown in Figure 116
on page 348.
3. From the Power Over Ethernet Configuration menu, type 3 to select
PoE Status.
The PoE Status menu is shown in Figure 119.
Figure 119. PoE Status Menu
The selections are defined below.
Allied Telesyn Ethernet Switch AT-8524POE - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
PoE Status
1 - PoE Global Status
2 - PoE Summary Ports Status
3 - PoE Detailed Ports Status
4 - PoE Device Information
R - Return to Previous Menu
Enter your selection?
