AT-S62 Management Software Menus Interface User’s Guide
Section I: Basic Operations 157
The Create LACP (IEEE 8023ad) Aggregator menu is shown in Figure
41 on page 155.
Figure 42. Create LACP (IEEE 8023ad) Aggregator Menu
5. Configure the parameters as necessary. The parameters are defined
here:
1 - Aggregator
Specifies a name for the aggregator. The name can be up to twenty
alphanumeric characters. Spaces are allowed, but special characters,
such as asterisks and exclamation points, are not. Each aggregator
must have a unique name.
2 - Adminkey
Specifies a unique adminkey value for the aggregator. The value is
entered in hexadecimal. The range is 1 to FFFF. For background
information, refer to “Adminkey Parameter” on page 142.
3 - Distribution Mode
Sets the load distribution method. Possible settings are:
ˆ SRC MAC - Source MAC address
ˆ DST MAC - Destination MAC address
ˆ SRC/DST MAC - Source address /destination MAC address
ˆ SRC IP - Source IP address trunking
ˆ DST IP - Destination IP address trunking
ˆ SRC/DST IP - Source address /destination IP address
The default is SRC/DST MAC. For background information, refer to
“Load Distribution Methods” on page 144.
4 - Port Range
Specifies the aggregator ports. An aggregator can contain any number
of ports on the switch. You can identify the ports individually (for
example, 3,7,10), as a range (for example, 5-11), or both (for example,
2,4,11-14).
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2006
Create LACP (IEEE 802.3ad) Aggregator
1 - Aggregator ..................
2 - Adminkey .................... 0x0000
3 - Distribution Mode ........... SRC/DST MAC
4 - Port Range ..................
C - Create Aggregator
R - Return to Previous Menu
Enter your selection?
