AT-S62 Management Software Menus Interface User’s Guide
Section V: VLANs 563
Example of Creating a Port-based VLAN
The following procedure creates the Sales VLAN illustrated in “Port-based
Example 1” on page 551. This VLAN will be assigned a VID of 2 and will
consist of four untagged ports, Ports 1 to 4. The VLAN will not contain any
tagged ports.
To create the Sales VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 188 on page 559.
2. From the VLAN Configuration menu, type 4 to select Configure
VLANs.
The Configure VLANs menu is shown in Figure 189 on page 560.
3. From the Configure VLANs menu, type 1 to select Create VLAN.
The Create VLAN menu is shown in Figure 190 on page 560.
4. Type 1 to select VLAN Name and enter “Sales”.
5. Type 2 to select VLAN ID (VID) and enter “2”. This is the VID value for
the new VLAN.
6. Type 4 to select Untagged Ports and enter “1-4”. These are the
untagged ports of the VLAN. Press Return.
Note
Option 5, Protected Ports, in the Create VLAN menu is not used to
create port-based or tagged VLANs. It must be left in the “No”
default setting. This option is explained in Chapter 27, “Protected
Ports VLANs” on page 615.
7. Type C to select Create VLAN.
8. After the switch displays the prompt notifying you that it created the
VLAN, press any key.
The new Sales VLAN has now been created.
9. After making changes, type R until you return to the Main Menu. Then
type S to select Save Configuration Changes.
