Energy Data Collector Configuration Chapter 3

Configure Advanced Device Parameters

Follow these steps to configure advanced demand parameters for the PowerMonitor 1000 device. These settings include
demand source, demand period length, and the number of demand periods to average for the demand calculation. The

Advanced Device Configuration Parameters

table on

page 65

shows the demand parameters and example settings.

1.

Choose Configure
Options>Advanced to
access the Advanced
Configuration page.

2.

Enter the default password
of 0 or another valid password to access Edit mode.

3.

Set appropriate values for the demand parameters
(elements 14, 15, and 16).

For this example, accept the default parameters as shown.

4.

Click Submit to send the parameter changes to the PowerMonitor 1000 device.

TIP

The password appears as asterisks (*).
If you don’t know the password, call
Rockwell Automation technical
support for assistance.

Advanced Device Configuration Parameters

Parameter

Range

Default

Example Settings

Password

0…9999

0

0

Demand Source

0…3

0 = Internal Timer

1 = Status Input 2

2 = Controller Command

3 = Ethernet Demand Broadcast

0

0

Demand Period Length

0…99 min

15 min

15

Number of Demand Periods

1…15

1

1

Forced Demand Sync Delay

0… 90 s

10

Demand Broadcast Master Select

0…1

0

Broadcast Port Number

(Ethernet Setup)

300… 400

300
