Rockwell Automation Energy Management Accelerator Toolkit Quick Start User Manual
Page 47
Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
47
System Configuration and Wiring Chapter 2
3.
Select the corresponding PLC-5 mapped address for the energy data point.
a. Select a cell in the PLC-5 Address column and click the pull-down list icon.
b. Choose a PLC-5 File 10 address to which the energy data point will be mapped for communicating with
FactoryTalk EnergyMetrix software.
For the Efficient Industries Plant 1 example, the Compactlogix and PLC-5 address assignments would look similar
to this.
TIP
It is recommended that you assign consecutive PLC-5 addresses in a single file to simplify mapping.
Refer to
