Rockwell Automation Energy Management Accelerator Toolkit Quick Start User Manual
Page 243
Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
243
FactoryTalk View ME Energy Faceplates
Chapter 11
Configure FactoryTalk View ME for the PowerMonitor 5000 Unit Faceplate
Follow these procedures to configure the faceplate.
Add PowerMonitor 5000 Unit Faceplate to ME Application
1. Launch FactoryTalk View Studio software and create or open an existing application file.
2. In the Graphics folder, right-click on Displays and choose ‘Add Component Into Application’.
3. Navigate to the ME PowerMonitor 5000 Faceplate Files folder, select the PowerMonitor5000_Faceplate, and click
Open.
