Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014

61

Energy Data Collector Configuration Chapter 3

Advanced Device Configuration Parameters

Parameter

Range

Default

Example Settings

New Password

-1

9999

0000

0000

Demand Period Length

-99

99 min

15

15

Number of Demand Periods

1

15

1

1

Forced Demand Delay

0

900 s

10

10

Predicted Demand Type

Instantaneous

1st Order

2nd Order

Instantaneous

KYZ Control Source

0 = None

1 = Wh Forward

2 = Wh Reverse

3 = VARh Forward

4 = VARh Reverse

5 = Vah

6 = Ah

7 = Setpoint

8 = Comms

7 = Setpoint

KYZ Pulse Output Scale

1

30000

10

KYZ Pulse Output Width

0, 40

2000

0

Relay Control Source

Same as KYZ

7 = Setpoint

Relay Pulse Output Scale

1

30000

10

Relay Pulse Output Width

0, 40

2000

100

RMS Resolution

Nominal / High

High

(2)

(2) Factory default for RMS Resolution is Nominal for the M4 and High for the M5, M6, and M8.

RMS Averaging

On / Off

On

Frequency Averaging

On / Off

On

Date Format

MM/DD/YYYY DD/MM/YYYY

MM/DD/YYYY

Date: Year

1998

2097

1998

Date: Month

1

12

1

Date: Day

1

31

1

Time: Hour

0

23

0

Time: Minutes

0

59

0

Time: Seconds

0

59

0

Default relay state on comms loss

0 = Last state/resume

1 = Last state/freeze

2 = De-energize/resume

3 = De-energize/freeze

0

Default KYZ state on comms loss

0

Wdog action

0 = Halt

1 = Continue

0 = Halt

Display Module Scroll Speed

Fast / Slow

Fast

Energy counter rollover point

4

15 digits

15

Metering Result Set (M8 only

(1)

)

(1) Metering result set parameter may only be configured by using communication.

0 = All results

1 = Transducer mode

2 = Energy meter mode

0 = All results
