Help view – Rockwell Automation Energy Management Accelerator Toolkit Quick Start User Manual
Page 421
Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
421
Time of Day Control Chapter 13
Help View
Press the Help button on any view to access the online help information.
Faceplate Toolbar
Help Screen Title
Next Page Button
Button
Icons
Description
Alarm
The alarm button indicates an alarm condition and activates alarm diagnostic views. A grey bell indicates normal
status, with no alarms. A red flashing bell indicates an alarm condition.
Configuration
The Configuration button lets you edit the Time of Day control settings, such as load schedules, overrides, time and
date configuration, and calendar configuration.
Home
The Home button lets you view the status of all 16 loads.
Next Page
The next button will appear if there is more than one help screen for the help topic. Click the next button to scroll
through the screens. The Help Screen Title will indicate the total number of help screens and the current screen
being displayed.
