Preface
Conventions
The manual uses the following conventions.
Software Requirements
You need the following software to use this toolkit.
Convention Meaning Example
Click
Click the left mouse button once to initiate an action. (Assumes cursor is positioned
on object or selection.)
Click Browse.
Double-click
To initiate an action, click the left mouse button twice in quick succession while the
cursor is positioned on object or selection.
Double-click the application icon.
Right-click
To initiate an action, click the right mouse button once while the cursor is positioned
on object or selection.
Right-click the Ethernet port.
Drag and drop
Click and hold the left mouse button on an object, move the cursor to where you
want to move the object, and release the mouse button.
Drag and drop a task into the blank plan.
Choose Choose an option from a list of options. From the Tools menu, choose Internet Options.
Select Click to highlight an item. Select the Devices folder.
Check or uncheck Click to activate or deactivate a checkbox. Check Enable device.
> Shows nested menu selections as menu name followed by menu selection. Choose File > New > Document.
Expand Click the + to the left of a given item /folder to show its contents. Expand the Main Task.
Rockwell Automation Software Version Required For
Studio 5000
 Logix Designer application
21.00 or later Power and energy management
applications
RSLogix
 5000
• ControlFlash
• BOOTP/DHCP utility
• RSLinx

Classic
17.00 or later
FactoryTalk View Studio for Machine Edition
• FactoryTalk Services
• RSLinx Enterprise
• RSLinx Classic 5.0 or later PanelView
 Plus terminals
FactoryTalk

EnergyMetrix™ CD,
cat. no. 9307-FTEMMENE
2.0 or later FactoryTalk EnergyMetrix software
Energy Management Accelerator Toolkit CD IASIMP-SP014 CAD files, wiring diagrams, application
files, and other support information
