Chapter
11
FactoryTalk View ME Energy Faceplates
Introduction
The Energy Management toolkit provides a variety of HMI faceplates for displaying real-time energy data and device
status/diagnostic information on plant floor HMI devices, such as PanelView Plus terminals and industrial computers.
Provides three phase voltage, current, and
frequency information.
Voltage, Current, Frequency View
Provides real, reactive, and apparent energy,
status count and demand data.
Energy View
Equipment Status Faceplate
Alarm History Faceplate
PowerMonitor 1000 Faceplate
Provides data collector device status and energy data information.
Provides date and time-stamped alarm and fault information for energy data
collector devices.
