182 Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
Chapter 9 FactoryTalk EnergyMetrix Software Reports and Charts
Billing Report
A billing report generates a replication of a monthly bill (shadow bill) from your energy provider, for comparative billing
analysis and potential energy cost recovery. The report is based on data from your energy meters and utility rate schedules.
Creating a billing report requires you to:
• add or import a rate schedule.
• set up, view, and print the report using the selected rate schedule.
For the Efficient Industries Plant 1 example, you will create a billing report for the electric utility.
Import or Create a Rate Schedule
A rate schedule defines a set of rules that FactoryTalk EnergyMetrix software uses to convert energy usage data into usable
billing or cost allocation information. For details on how to configure rate schedules, refer to the FactoryTalk EnergyMetrix
software online help.
For your convenience, the Energy Management Accelerator Toolkit CD provides sample rate schedules that you can import
and modify for your needs.
Sample Rate Schedules
Rate Schedule Description
AEP Indiana Michigan Power Company Tariff IP Includes demand charges based on kVA, power factor penalty if < 0.85 , secondary
metering correction factor of 1.01, time of use on and off peak, and no seasons or
holidays.
Alliant Cg-2 TOD Includes summer and winter seasons with different rates, time of use on and off peak,
and no holidays.
Alliant Cp-1 - 12 hr 10-10 Includes holidays, summer and winter seasons with different rates, time of use on and
off peak, global variables, and hidden line items for preliminary calculations.
Alliant IP Incudes seasons based on Daylight Savings Time (DST) start and end dates in 2007.
For accuracy, seasons should be adjusted for DST each year. The value type EAC is
needed for manual meter to store monthly energy adjustment rates.
Rate schedule is based on Alliant IP&L tariff sheet 26 issued on June 26, 2006.
Black Hills Power General Service 20 Includes global variables, hidden line items for preliminary calculations, stepped
(banded) energy and demand charges, and a power factor penalty < 0.85.
Rate schedule does not include seasons, holidays, or times of use.
Dominion VA Power Non-Residential Sched 130 Includes summer and winter seasons with different rates, time of use with different
season schedules, global variables, hidden line items for preliminary calculations, and
several fixed facility charges.
Progress Energy LGS-9 Includes seasons for ratchet demand calculation, stepped (banded) demand charges,
global variables, global proration factor for partial month reporting.
Virginia Electric and Power Company GS-4 Includes summer and winter seasons, time of use with different season schedules,
global variables, and many riders.
WE General Primary Service TOU Cp1 Includes holidays, global variables, sales tax, and blended rate per kWh calculation.
