Rockwell Automation Energy Management Accelerator Toolkit Quick Start - Manual (Page 55)

Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014 55
Chapter
3
Energy Data Collector Configuration
Introduction
In this chapter, you configure data collector devices for your energy management application. This can include
PowerMonitor W250, 500, 1000, 3000, or 5000 devices and CompactLogix controllers.
PowerMonitor devices typically gather electrical energy data through connections to electrical distribution systems. In
addition, PowerMonitor devices can connect to digital pulse outputs from gas, water, and other types of energy meters.
The CompactLogix controller collects energy data from digital or analog outputs of meters and transmitters for a variety of
energy sources such as water, air, gas, steam, electric, and fuel. The controller also provides an interface to HMI devices
providing energy data and device status to the plant floor.
Before You Begin
• Determine business goals, complete energy assessment, and determine monitoring methods ( Chapter 1 ).
• Select hardware and wire devices ( Chapter 2 ).
What You Need
• Supporting hardware identified in the Energy Data Worksheet for your system, which includes:
– PowerMonitor 1000 device
– PowerMonitor 3000 master module and display module
– PowerMonitor W250 device
– PowerMonitor 500 device
– PowerMonitor 5000 device
– CompactLogix controller
• RSLogix 5000 software, version 17 or later or Studio 5000 Logix Designer application, version 21.00 or later
• Energy Management Accelerator Toolkit, publication IASIMP-SP014
or visit the Integrated Architecture Tools and Resources website at http://www.ab.com/go/iatools
• Product manuals:
– Bulletin 1404 PowerMonitor 3000 Unit User Manual, publication 1404-UM001
– PowerMonitor 3000 Installation Instructions, publication 1404-IN007
– PowerMonitor 1000 Unit User Manual, publication 1408-UM001
– PowerMonitor 1000 Unit Installation Instructions, publication 1408-IN001
– PowerMonitor W250 Unit User Manual, publication 1425-UM001
– PowerMonitor 500 Unit User Manual, publication 1420-UM001
– PowerMonitor 5000 Unit User Manual, publication 1426-UM001
– Logix Common Procedures Programming Manual, publication 1756-PM001
