Configure advanced device, Parameters – Rockwell Automation Energy Management Accelerator Toolkit Quick Start User Manual
Page 60
60
Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
Chapter 3 Energy Data Collector Configuration
Configure Advanced Device Parameters
The
Advanced Device Configuration Parameters
table on
provides a list of advanced parameters and values you can
set for the PowerMonitor 3000 device. Most applications use the default values for demand period length, number of
demand periods, and forced demand delay.
Follow these basic steps to configure demand parameters and the date/time.
1.
Press the Enter key from the PROG.>CONFIGURATION menu.
The BASIC configuration menu is displayed.
2.
Press the Down Arrow key to select the ADVANCED menu, then press the Enter key.
3.
Press the Down Arrow key to select the desired advanced parameter.
4.
Press the Enter key to access Edit mode.
5.
Press the Up and Down Arrow keys to change the value.
6.
Press the Enter key to write the new value to the PowerMonitor 3000 master module and set the display module back
to Program mode.
7.
Repeat steps 3…6 to set other advanced parameters.
8.
Press the Escape key to return to desired menus.
