Rockwell Automation Energy Management Accelerator Toolkit Quick Start User Manual
Page 365
Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
365
Demand Control Chapter 12
2.
Expand the Tasks folder in your Controller Organizer, right click the Main Task
folder, and select Import Program.
3.
Browse to and open the Demand Control Logic folder on the Energy Management
Accelerator Toolkit CD image.
C:\Program Files\RA_Simplification\EMAT\File\Demand
Control Logic.
4.
Select the DemandControl.L5x file and click Import.
The Import Configuration dialog will appear.
5.
Leave the program properties at the default; click
OK to create the Demand Control program.
6.
The new DemandControl program should
appear in the Controller Organizer within the Main Task folder.
