Rockwell Automation Energy Management Accelerator Toolkit Quick Start User Manual
Page 51
Rockwell Automation Publication IASIMP-QS016C-EN-P - October 2014
51
System Configuration and Wiring Chapter 2
Access Other Allen-Bradley CAD Drawings
Follow these steps to download other Allen-Bradley® product CAD drawings.
1.
ttp://ab.com/e-tools.
The Configuration and Selection Tools webpage opens.
2.
If you don’t know the complete catalog number,
click product directory to browse the configured
Rockwell Automation products.
3.
Click Rockwell Automation and follow the
prompts.
TIP
If you know the complete catalog number of your Allen-Bradley product, you can enter it here and click Submit.
However, you need a complete catalog number string to get the configuration results.
