FactoryTalk EnergyMetrix Software Meter and Tag Setup Chapter 7
Create a PowerMonitor Electric Meter
Follow these steps to create a PowerMonitor electric meter.
1. Click the Meters tab.
2. Navigate to and select a group to
assign the meter.
For this example, select
Electricity under the
Engineering subdomain.
3. Click the Meters tab on the
right.
4. Click the Add a new meter link.
5. Select the Parent group.
For this example, select Electricity.
6. Choose the meter type.
For this example, choose Electric.
7. Choose the device associated with the
meter.
For this example, choose Boiler House.
8. Enter a meter name.
For this example, enter Boiler House
Meter.
9. Click Save.
10. Confirm the meter was created in the
correct group.
