Module Configuration Definitions
3.5.20 MECHATROLINK Definitions
3-108
3
The settings are divided into four tab pages, as shown in the following table.
„ The MECHATROLINK Definitions Window Menus
The following table shows the functions of the menu commands in the MECHATROLINK
Definitions Window.
„ Setting MECHATROLINK Definitions
Transmission Parameters Tab Page
This tab sets the parameters required to use the MECHATROLINK communications system.
Transmission Parameters Sets the MECHATROLINK transmission parameters.
I/O Assignment Allocates the MECHATROLINK's I/O.
I/O Map Sets the I/O map.
Status Displays the transmission status.
Menu Command Function
Edit (E)
Parameter Setting (D) Returns the allocation settings to default values.
Assignment Delete (A) Clears the allocation settings.
Setting Item Details
Master/Slave Sets whether the Machine Controller is used as a Master station or a
Slave station.
Own Station Address When the Machine Controller is being used as a master station, the
local station address is fixed at 0 and cannot be changed. When it is
being used as a slave station, set a station address between 1 and 30.
Message Trust Level Sets the error recovery level for sending MEMOBUS commands.
0 Send command just once and wait indefinitely for a response
from the destination.
1 Send command once and resend if a response is not received
within 8 seconds.
2 When sending the command, send each word of data twice
consecutively and wait indefinitely for a response from the
destination. This method improves transmission quality but
reduces transmission efficiency by 50%.
